generator engine diesel
Rated AC Voltage(V)：110V/220V/380V
Frequency(HZ):50HZ/60HZ
Engine Speed(R.P.M):1500-3000
Phase:Single/Three Phase
Type:Silent/Open FrameEngine
Type:Two/Four cylinder
Cooling Method: Water Cooling
Starting Method:Electric Starting
Customization: OEM/ODM
Certificates: CE/Euro 5/EPA/CARB
- Product Description
JLMECH: Your Trusted Generator Engine Diesel Manufacturer & Supplier
Wuhan Jlmech Co., Ltd. specializes in designing and manufacturing generator engine diesel solutions for industrial and commercial applications. With 3 R&D centers, 26 global offices, and partnerships with brands like Cummins and Perkins, we deliver durable, fuel-efficient engines backed by a 2-year warranty. Our ISO-certified processes ensure reliability for industries like construction, healthcare, and data centers.
Generator Engine Diesel Description
Our generator engine diesel units are engineered for performance in demanding environments. Ideal for backup power or remote operations, they combine high torque, low fuel consumption, and compliance with emissions standards like Tier 4. Choose from 20 kVA to 500 kVA models, customizable for silent operation, containerization, or hybrid fuel compatibility.
Specifications
| Rated frequency | Diesel engine | Standard power | Rated current (A) | Rated voltage | Rated frequency | Bore × Stroke (mm) | Rated speed | Type | cylinder | Dimensions (cm) | Weight (kg) |
| JL-30GF | K4100D | 30.1kW | 54A | 400V/230V | 50Hz | 100*115 | 1500rpm | inline four-stroke water-cooled direct injection | 4 | 165*65*110 | 500kg |
| JL-40GF | K4100ZD | 41kW | 72A | 400V/230V | 50Hz | 100*115 | 1500rpm | 4 | 165*65*110 | 540kg | |
| JL-50GF | ZH4105ZD | 55kW | 90A | 400V/230V | 50Hz | 105*125 | 1500rpm | 4 | 175*63*104 | 600kg | |
| JL-50GF | R4105ZD | 56kW | 90A | 400V/230V | 50Hz | 105*125 | 1500rpm | 4 | 175*73*110 | 750kg | |
| JL-75GF | R6105ZD | 85kW | 135A | 400V/230V | 50Hz | 105*130 | 1500rpm | 6 | 234*73*120 | 900kg | |
| JL-100GF | R6105AZLD | 121kW | 180A | 400V/230V | 50Hz | 105'130 | 1500rpm | 6 | 234*73*120 | 1050kg | |
| JL-120GF | R61051ZLD | 132kW | 216A | 400V/230V | 50Hz | 105*135 | 1500rpm | 6 | 234*73*120 | 1050kg | |
| JL-150GF | R6105IZLD | 151kW | 270A | 400V/230V | 50Hz | 105*135 | 1500rpm | 6 | 234*73*120 | 1100kg | |
| JL-150GF | R6110ZLD | 155kW | 270A | 400V/230V | 50Hz | 110*135 | 1500rpm | 6 | 234*75*130 | 1120kg | |
| JL-200GF | 6126ZLD | 206kW | 360A | 400V/230V | 50Hz | 126*130 | 1500rpm | 6 | 290*95*150 | 1800kg | |
| JL-250GF | 6126ZLD1 | 256kW | 450A | 400V/230V | 50Hz | 126*130 | 1500rpm | 6 | 290*95'150 | 1800kg | |
| JL-300GF | 6126ZLD2 | 308kW | 540A | 400V/230V | 50Hz | 126*130 | 1500rpm | 6 | 290*95*150 | 1900kg | |
| JL-300GF | 618ZLD | 338kW | 540A | 400V/230V | 50Hz | 126*155 | 1500rpm | 6 | 300*100*180 | 2000kg | |
| JL-400GF | 6126ZLD3 | 408kW | 720A | 400V/230V | 50Hz | 126*155 | 1500rpm | 6 | 300*110"160 | 2000kg | |
| JL-500GF | 6126ZLD4 | 508kW | 900A | 400V/230V | 50Hz | 127*165 | 1500rpm | 6 | 340*110*180 | 2400kg |
The rotational speed in the above Ricardo generator set technical parameters is 1500 RPM, the frequency is 50 Hz, the rated voltage is 400/230V, the power factor is 0.8, and the wiring method is three-phase four-wire. The 60 Hz generator sets and generator brands can be customized according to the special needs of customers. This parameter table is for reference only. For details, please contact our customer service.Why Choose US?
- Proven Reliability: Tested for 500+ hours under extreme conditions.
- Global Support: 26 overseas offices in Africa and Southeast Asia ensure quick spare parts and maintenance.
- OEM Expertise: We manufacture engines for Cummins, Perkins, and MTU, guaranteeing industry-leading quality.
- Cost Efficiency: Optimized fuel consumption reduces your total ownership cost.
Packaging and Delivery
Generator engine diesel is crated in weatherproof, shock-resistant packaging. Delivery timelines: 15–30 days (standard models) or 45–60 days (customized).
Company Profile
Founded in 2005, Wuhan Jlmech employs 126 technical experts across 11 Chinese branches. Our 52,000 m² facility includes automated assembly lines and testing labs to ensure precision.
Factory After-Sales Service
Enjoy a 2-year warranty, 24/7 technical support, and on-site maintenance contracts.
Certification
ISO9001 (quality management) and ISO14001 (environmental compliance) certified.
Exhibitions
We showcase innovations at global trade fairs like PowerGen Asia and Middle East Energy.
FAQ
Q: Can your engines withstand tropical climates?
A: Yes! Our corrosion-resistant coatings and enhanced cooling systems are tested for high humidity.
Q: Do you offer hybrid or biodiesel-compatible models?
A: Customizable options are available. Contact our team for details.
Q: How do I calculate the right engine size?
A: Share your load requirements, and our engineers will recommend a model.
Trusted by Industries Worldwide
From powering Lagos hospitals to Indonesian mining sites, our generator engine diesel units keep businesses running. With CE and ISO certifications, transparent pricing, and OEM-grade engineering, we're committed to your operational success.Contact us today at skala@whjlmech.com for a tailored quote!
