150kw diesel generator noiseless
Noise Level: ≤68 dB at 7 meters
Fuel Consumption: 32 L/hr at 75% load
Engine: Turbocharged diesel, Tier III compliant
Voltage: 380-415V, 50/60Hz
Dimensions: 2900 x 950 x 1500mm (containerized options available)
- Product Description
JLMECH: Your Trusted 150kW Diesel Generator Noiseless Manufacturer & Supplier
For over 26 years, Wuhan Jlmech Co., Ltd. has specialized in designing 150kW diesel generator noiseless units trusted by global industries. With ISO-certified manufacturing, OEM partnerships (Cummins, Perkins, etc.), and a 2-year warranty, our generators deliver silent, reliable power for hospitals, data centers, construction sites, and more.
150kW Diesel Generator Noiseless Description
Engineered for minimal noise (≤68 dB at 7 meters) and maximum efficiency, our 150kW diesel generator noiseless combines a soundproof canopy with advanced vibration control. Ideal for urban areas, hospitals, or outdoor events, it meets strict emission standards (ISO 8528, CE) and adapts to extreme temperatures (-20°C to 50°C).
Specifications
| Rated frequency | Diesel engine | Standard power | Rated current (A) | Rated voltage | Rated frequency | Bore × Stroke (mm) | Rated speed | Type | cylinder | Dimensions (cm) | Weight (kg) |
| JL-30GF | K4100D | 30.1kW | 54A | 400V/230V | 50Hz | 100*115 | 1500rpm | inline four-stroke water-cooled direct injection | 4 | 165*65*110 | 500kg |
| JL-40GF | K4100ZD | 41kW | 72A | 400V/230V | 50Hz | 100*115 | 1500rpm | 4 | 165*65*110 | 540kg | |
| JL-50GF | ZH4105ZD | 55kW | 90A | 400V/230V | 50Hz | 105*125 | 1500rpm | 4 | 175*63*104 | 600kg | |
| JL-50GF | R4105ZD | 56kW | 90A | 400V/230V | 50Hz | 105*125 | 1500rpm | 4 | 175*73*110 | 750kg | |
| JL-75GF | R6105ZD | 85kW | 135A | 400V/230V | 50Hz | 105*130 | 1500rpm | 6 | 234*73*120 | 900kg | |
| JL-100GF | R6105AZLD | 121kW | 180A | 400V/230V | 50Hz | 105'130 | 1500rpm | 6 | 234*73*120 | 1050kg | |
| JL-120GF | R61051ZLD | 132kW | 216A | 400V/230V | 50Hz | 105*135 | 1500rpm | 6 | 234*73*120 | 1050kg | |
| JL-150GF | R6105IZLD | 151kW | 270A | 400V/230V | 50Hz | 105*135 | 1500rpm | 6 | 234*73*120 | 1100kg | |
| JL-150GF | R6110ZLD | 155kW | 270A | 400V/230V | 50Hz | 110*135 | 1500rpm | 6 | 234*75*130 | 1120kg | |
| JL-200GF | 6126ZLD | 206kW | 360A | 400V/230V | 50Hz | 126*130 | 1500rpm | 6 | 290*95*150 | 1800kg | |
| JL-250GF | 6126ZLD1 | 256kW | 450A | 400V/230V | 50Hz | 126*130 | 1500rpm | 6 | 290*95'150 | 1800kg | |
| JL-300GF | 6126ZLD2 | 308kW | 540A | 400V/230V | 50Hz | 126*130 | 1500rpm | 6 | 290*95*150 | 1900kg | |
| JL-300GF | 618ZLD | 338kW | 540A | 400V/230V | 50Hz | 126*155 | 1500rpm | 6 | 300*100*180 | 2000kg | |
| JL-400GF | 6126ZLD3 | 408kW | 720A | 400V/230V | 50Hz | 126*155 | 1500rpm | 6 | 300*110"160 | 2000kg | |
| JL-500GF | 6126ZLD4 | 508kW | 900A | 400V/230V | 50Hz | 127*165 | 1500rpm | 6 | 340*110*180 | 2400kg |
The rotational speed in the above Ricardo generator set technical parameters is 1500 RPM, the frequency is 50 Hz, the rated voltage is 400/230 V, the power factor is 0.8, and the wiring method is three-phase four-wire. The 60 Hz generator sets and generator brands can be customized according to the special needs of customers. This parameter table is for reference only. For details, please contact our customer service.
Why Choose US?
- Proven Expertise: 52 engineers across 3 R&D centers optimize performance and durability.
- Global Compliance: CE, ISO 8528, and EPA-certified for worldwide use.
- Silent Operation: Patented noise-reduction technology ensures compliance with urban regulations.
- OEM Experience: Trusted by Cummins, Perkins, and MTU for precision engineering.
Packaging and Delivery
All units are crated in anti-corrosion packaging, with global shipping via sea/air. Delivery includes installation manuals and a spare parts kit.
Company Profile
Wuhan Jlmech Co., Ltd. operates 11 branches in China and 26 overseas offices, supported by 126 technical experts. Our automated production lines and 2-year warranty guarantee reliability.
Factory After-Sales Service
A dedicated team in Africa and Southeast Asia provides 24/7 support, maintenance contracts, and emergency repairs.
Certification
Our generators meet CE, ISO 8528, and GB/T 2820-97 standards, with ISO 9001/14001 management systems.
Exhibitions
We showcase innovations at POWERGEN, Bauma, and regional trade shows.
FAQ
Q: Can it integrate with solar/hybrid systems?
A: Yes—customizable for hybrid setups.
Q: Noise compliance for EU regions?
A: ≤68 dB meets EU Stage V regulations.
Q: Bulk order discounts?
A: Contact us for tiered pricing.
Q: Lead time?
A: 15–25 days, depending on configuration.
Need a Silent Power Solution?
Email skala@whjlmech.com to discuss your 150kW diesel generator noiseless requirements. Let's power your operations—quietly and reliably.
