mute diesel generator
Rated AC Voltage(V)：110V/220V/380V
Frequency(HZ):50HZ/60HZ
Engine Speed(R.P.M):1500-3000
Phase:Single/Three phase
Type:Silent/Open Frame
Engine Type:Two/Four cylinder
Cooling Method: water Cooling
Starting Method:Electric starting
Customization: OEM/ODM
Certificates: CE/Euro 5/EPA/CARB
- Product Description
JLMECH：Your Trusted Mute Diesel Generator Manufacturer & Supplier
Wuhan Jlmech Co., Ltd. specializes in designing mute diesel generators that combine industrial-grade power with whisper-quiet operation. With 3 R&D centers, 52 engineers, and global certifications (CE, ISO8528), our generators deliver 65 dB noise levels, fuel efficiency, and 24/7 reliability. As an OEM partner for Cummins, Perkins, and MTU, we ensure premium quality for bulk buyers in construction, healthcare, and telecom sectors.
Mute Diesel Generator Description
Our mute diesel generators are engineered for industries requiring uninterrupted power without noise disruption. Featuring soundproof canopies and vibration-dampening technology, these units operate below 65 dB—ideal for urban hospitals, data centers, or outdoor events. Customizable from 10kVA to 3000kVA, they support automated transfer switches (ATS) and comply with EPA Tier 4/Stage V emissions.
Specifications
| Model | Power （KW） | Power (KVA) | Current (A) | Engine model | Cylinder | Bore*Stroke(mm) | Displacement(L) | Lube oil(L) | Consumption (g/kw.h) | Size (mm) | Weight (Kg) |
| JL-20GF | 20 | 25 | 36 | WP2.3D25E200 | 4 | 89*92 | 2.289 | 8 | 224 | 1800*900*1270 | 755 |
| JL-30GF | 30 | 37.5 | 54 | WP2.3D33E200 | 4 | 89*92 | 2.289 | 8 | 212 | 1800*900*1300 | 800 |
| JL-60GF | 60 | 75 | 108 | WP4.1D66E200 | 4 | 105*118 | 4.087 | 13 | 235 | 1950*920*1340 | 1100 |
| JL-70GF | 70 | 87.5 | 126 | WP4.1D80E200 | 4 | 105*118 | 4.087 | 13 | 235 | 1850*700*1200 | 1000 |
| JL-80GF | 80 | 100 | 144 | WP4.1D100E200 | 4 | 105*130 | 4.5 | 10 | 203 | 2200*800*1340 | 1250 |
| JL-90GF | 90 | 112.5 | 162 | WP4D100E200 | 4 | 105*118 | 4.5 | 13 | 201 | 2200*800*1340 | 1250 |
| JL-120GF | 120 | 150 | 216 | WP60132E200 | 6 | 105*130 | 6.75 | 18 | 205 | 2470*830*1450 | 1350 |
| JL-132GF | 132 | 165 | 238 | WP6D152E200 | 6 | 105*130 | 6.75 | 18 | 205 | 2470*930*1450 | 1400 |
| JL-150GF | 150 | 87.5 | 270 | WP60167E200 | 6 | 105*130 | 6.75 | 18 | 201 | 2550*950*1300 | 1430 |
| JL-180GF | 180 | 225 | 324 | WP10D200E200 | 6 | 126*130 | 9.726 | 24 | 215 | 2750*1050*1400 | 1880 |
| JL-200GF | 200 | 250 | 360 | WP10D238E200 | 6 | 126*130 | 9.726 | 24 | 215 | 2750*1050*1500 | 2100 |
| JL-220GF | 220 | 275 | 396 | WP10D264E200 | 6 | 126*130 | 9.726 | 24 | 215 | 2900*1100*1550 | 2200 |
| JL-280GF | 280 | 350 | 504 | WP10D320E200 | 6 | 126*130 | 9.726 | 24 | 210 | 2900*1100*1800 | 2200 |
| JL-280GF | 280 | 350 | 504 | WP12D317E200 | 6 | 125*155 | 11.596 | 24 | 210 | 2900*1200*1800 | 2300 |
| JL-350GF | 350 | 437.5 | 630 | WP13D385E200 | 6 | 127*165 | 12.54 | 36 | 210 | 3000*1000*1850 | 2500 |
| JL-350GF | 350 | 437.5 | 630 | WP13D405E200 | 6 | 127*165 | 12.54 | 36 | 200 | 3000*1000*1850 | 2600 |
| JL-400GF | 400 | 500 | 720 | 6M26D447E200 | 6 | 150*150 | 15.9 | 52 | 197 | 3500*1500*1800 | 4000 |
| JL-440GF | 440 | 550 | 792 | 6M26D484E200 | 6 | 150*150 | 15.9 | 52 | 210 | 3500*1500*1800 | 4100 |
| JL-500GF | 500 | 625 | 900 | 6M33D572E200 | 6 | 150*185 | 19.6 | 61 | 210 | 3600*1500*1850 | 5000 |
| JL-550GF | 550 | 687.5 | 990 | 6M33D633E200 | 6 | 150*185 | 19.6 | 61 | 210 | 3600*1500*1900 | 5500 |
| JL-600GF | 600 | 750 | 1080 | 6M33D670E200 | 6 | 150*185 | 19.6 | 61 | 210 | 3650*1500*1900 | 6000 |
The rotational speed in the above Weichai generator set technical parameters is 1500 RPM, the frequency is 50 Hz, the rated voltage is 400/230V, the power factor is 0.8, and the wiring method is three-phase four-wire. The 60 Hz generator sets and generator brands can be customized according to the special needs of customers. This parameter table is for reference only. For details, please contact our customer service.
Why Choose US?
- Proven Expertise: 27 senior engineers refine designs for reduced noise and emissions.
- Global Compliance: Meet EU, African, and Asian regulatory standards effortlessly.
- Hybrid Readiness: Integrate solar/battery systems for hybrid energy cost savings.
- OEM-Grade Quality: Components from Cummins, Stamford, and Leroy-Somer ensure longevity.
- 2-Year Warranty: Full coverage for mechanical and electrical parts.
Packaging and Delivery
Every soundproof diesel generator is crated in anti-rust treated wood, with shock-absorbent padding and waterproof wrapping. We ship via DDP incoterms to Africa, Southeast Asia, and Europe within 15–30 days.
Company Profile
With 11 branches in China and 26 overseas offices, Wuhan Jlmech serves clients in 40+ countries. Our 126 technical staff and automated assembly lines guarantee precision in every mute diesel generator.
Factory After-Sales Service
Enjoy free remote troubleshooting, on-site repairs in 48 hours (Asia/Africa), and genuine spare parts access.
Certification
ISO9001, ISO14001, CE, and EPA-compliant manufacturing processes.
Exhibitions
Showcased at PowerGen Asia, Middle East Energy, and Bauma China.
FAQ
Q: Can your generators withstand extreme temperatures?
A: Yes! Units are tested from -20°C to 55°C for desert or Arctic use.
Q: Do you offer leasing options?
A: Flexible CAPEX/OPEX models available for phased deployments.
Q: How do I verify noise levels?
A: We provide third-party test reports with every shipment.
Q: Can I customize the canopy color?
A: Choose from RAL codes or corporate branding.
Ready to Upgrade to Silent Power?
Join 500+ enterprises relying on Wuhan Jlmech's mute diesel generators for noiseless, dependable energy. Contact us at skala@whjlmech.com for bulk quotes or hybrid solutions.
