power plants diesel generator water cooled silent

AC Output(KW)：20-3000KW
Rated AC Voltage(V)：110V/220V/380V
Frequency(HZ):50HZ/60HZ
Engine Speed(R.P.M):1500-3000
Phase:Single/Three Phase
Type:Silent/Open Frame
Engine Type:Two/Four cylinder
Cooling Method: Water Cooling
Starting Method:Electric Starting
Customization: OEM/ODM
Certificates: CE/Euro 5/EPA/CARB

Product Description

JLMECH:Your Trusted Power Plants Diesel Generator Water Cooled Silent Manufacturer & Supplier

Wuhan Jlmech Co., Ltd. specializes in designing high-performance,power plants diesel generator water cooled silent for power plants. With 29+ years of expertise, 3 R&D centers, and partnerships with global brands like Cummins and Perkins, our generators deliver unmatched reliability, noise compliance (≤65 dB), and 24/7 operational durability. Certified to CE, ISO, and GB/T standards, we ensure seamless integration into critical infrastructure.

Power Plants Diesel Generator Water Cooled Silent Description

Our power plants diesel generator water cooled silent is engineered for power plants requiring uninterrupted energy in demanding environments. Featuring advanced cooling systems and noise-dampening enclosures, these units operate at ≤65 dB, making them ideal for urban zones, hospitals, and industrial complexes. Customizable power outputs (50kVA–3000kVA) and fuel flexibility (diesel, biodiesel) ensure compatibility with diverse project needs.

power plants diesel generator water cooled silent

Specifications

Model	Power (KW)	Power (KVA)	Current( A)	Engine model	Cylinder	Bore×Stroke（mm）	Displacement (L)	Lube oil (L)	Consumption (g/kw.h)	Size (mm)	Weight (Kg)
JL-50GF	50.0	62.5	90	YCD4J22D-65	4	105*125	4.33	11	225	18008001100	940
JL-100GF	100	125	180	YC68155L-D21	6	108*125	6.B7	20	196	25008001250	1500
JL-120GF	120	150	216	YC68180L-D20	6	108*125	6.87	20	196	25008301300	1600
JL-132GF	132	165	237.6	YC6B205L-D20	6	108*125	6.87	20	196	25008501300	1700
JL-150GF	150.0	187.5	270	YC6A230L-D20	6	108*132	7.26	21	195	25509001350	2100
JL-160GF	160	200	288	YC6A245L-D21	6	108*132	7.26	21	195	25009701500	2300
JL-180GF	180	225	324	YC6MK285L-D20	6	123*145	10.33	28	195	30001030*1550	2600
JL-300GF	300	375	540	YC6MJ48DL-D20	6	131*145	11.73	28	215	3100*11501750	3100
JL-400GF	400	500	720	YC6T600L-D22	6	145*165	16.35	52	195	350013501780	3900
JL-600GF	600	750	1080	YC6ID900-D31	6	152*180	19.6	52	225	375016502000	4500
JL-1320GF	1320	1650	2376	YC12VC2070-D31	12	200*210	79.17	280	210	540023002600	10000
JL-2000GF	2000	2500	3600	YC16VC3000-D31	16	200*210	105.6	430	196	735026702950	17500
JL-2200GF	2200	2750	3960	YC16VC3300-D31	16	200*210	105.6	430	196	735026702950	17580
JL-2400GF	2400	3000	4320	YC16VC3600-D31	16	200*210	105.6	430	196	740031003300	19200

The silent generator of China Yuchai has the advantages of low noise, stable power generation, strong power and durability.

The rotational speed in the above technical parameters is 1500 RPM, the frequency is 50 Hz, the rated voltage is 400/230 V, the power factor is 0.8, and the wiring method is three-phase four-wire. The 60 Hz generator sets and generator brands can be customized according to the special needs of customers. This parameter table is for reference only. For details, please contact our customer service.

Why Choose Wuhan Jlmech?

Proven Expertise: 52 engineers and 27 senior engineers drive innovation.
Global Compliance: Meets EPA Tier 4 and EU Stage V emissions standards.
OEM Partnerships: Trusted by Cummins, Perkins, and MTU for precision engineering.
Warranty & Support: 2-year warranty + 24/7 global technical assistance.
Scalable Solutions: Custom configurations for hybrid energy systems or IoT integration.

Packaging and Delivery

Power plants diesel generator water cooled silent is crated in anti-corrosion steel frames and shipped globally via air/sea freight. Delivery timelines: 15–30 days (standard), 45–60 days (custom orders).

Company Profile

Generator factory

Since 1998, Wuhan Jlmech has served 1,200+ clients across 30 countries. With 11 branches in China and 26 overseas offices, our 126 technical staff ensure cutting-edge solutions for power generation, mining, and data centers.

Factory After-Sales Service

Comprehensive support includes on-site maintenance, spare parts supply, and emergency troubleshooting. Our ISO9001-certified team guarantees rapid response times.

Certification

Certificate

Certified to CE, ISO8528, ISO9001, and ISO14001. Compliant with UL, GS, and GB/T standards.

Exhibitions

We showcase innovations at PowerGen International, Middle East Electricity, and ASEAN Energy Week.

FAQ

Q: Can generators be integrated with solar/hybrid systems?
A: Yes! Our units support hybrid configurations for future scalability.

Q: What's the lead time for 100 units?
A: 30–45 days, depending on customization.

Q: Do you provide onsite installation training?
A: Absolutely. Our engineers assist with setup and operator training.

Trusted by Global Leaders. Built for Your Power Needs

Need a power plants diesel generator water cooled silent that balances performance and compliance? Contact us at skala@whjlmech.com for a tailored quote.
