cultivator machine farm cultivator
Power Type:Gasoline/Diesel
Transmission:Gear
Handlebar System:UP Down Left Right
Warranty:2 Years
Usage:Gardern or Farm Culticator
Tilling Depth:≥100mm
Sustomized Support: OEM, ODM, OBM
Certificates: CE/ROHS
- Product Description
JLMECH：Your Trusted Cultivator Machine Farm Cultivator Manufacturer & Supplier
Wuhan Jlmech Co., Ltd. is a trusted cultivator machine farm cultivator manufacturer and supplier, combining 126 technical experts, advanced production facilities, and globally recognized certifications (CE, ISO, GB/T) to deliver durable, precision-engineered equipment. As an OEM partner for Cummins, Perkins, and Liebherr, we ensure reliability, fuel efficiency, and compliance with international standards.
Cultivator Machine Farm Cultivator Description
Our cultivator machine farm cultivator is designed for large-scale agricultural operations, offering unmatched efficiency in soil preparation and weed control. Built to withstand diverse terrains, it integrates GPS-ready technology for precision farming, reducing labor costs by 30% while boosting crop yields. Ideal for commercial farms and cooperatives, it adapts to clay, loam, and sandy soils with adjustable tilling depths (6–18 inches).
Specifications
| Product name | JLBL900G | JLBL950G | JLBL1000D | JLBL1050G | JLBL1050D | JLBL1350G | JLBL1350D |
| Operation Method | Handheld | Handheld | Handheld | Handheld | Handheld | Handheld | Handheld |
| Transmission | Gear | Gear | Gear | Gear | Gear | Gear | Gear |
| Clutch Type | Belt &Chain | Friction plate | Friction plate | Friction plate | Friction plate | Friction plate | Friction plate |
| Gear Shifting | 2 , 0 , 1 , -1 | 2 , 0 , 1 , -1 | 2 , 0 , 1 , -1 | 2 , 0 , 1 , -1 | 2 , 0 , 1 , -1 | 2 , 0 , 1 , -1 | 2 , 0 , 1 , -1 |
| Gross Weight | 70kg | 65kg | 75kg | 110kg | 115kg | 115kg | 135kg |
| Net Machine Weight | 65kg | 52kg | 70kg | 105kg | 110kg | 110kg | 130kg |
| Handlebar left-right range | 360℃ | 360℃ | 360℃ | 360℃ | 360℃ | 360℃ | 360℃ |
| Handlebar up-down range | 160℃ | 130℃ | 80℃ | 80℃ | 120℃ | 120℃ | 120℃ |
| Number of Blades | 24 | 24 | 24 | 32 | 32 | 40 | 40 |
| Tilling Depth | ≥100mm | ≥100mm | ≥100mm | ≥100mm | ≥100mm | ≥100mm | ≥100mm |
| Tilling Width | 900mm | 950mm | 1000mm | 1050mm | 1050mm | 1350mm | 1350mm |
| Tire Size | 350-6 inch | 350-6 inch | 350-6 inch | 400-8 inch | 400-8 inch | 400-8 inch | 400-8 inch |
| Blade Type | Dry Land Blade and Wet Land Blade & Plough Optional | ||||||
| Engine Model | 170F | 170F | 173F | 177F | 178F | 190F | 186FA |
| Fuel type | Gasoline | Gasoline | Diesel | Gasoline | Diesel | Gasoline | Diesel |
| Bore*Stroke | 70*55mm | 70*55mm | 73*59mm | 77*58mm | 78*62mm | 90*66mm | 86*72mm |
| Fuel Tank Capacity | 3.6L | 3.6L | 2.5L | 6L | 3.5L | 6L | 5.5L |
| Displacement | 212cc | 212cc | 247cc | 240cc | 296cc | 420cc | 418cc |
| Max. Power | 7.5HP | 7.5HP | 5.5HP | 9HP | 7HP | 12HP | 10HP |
| Starting Method | Recoil Start; Electric Start Optional | ||||||
| Package Size | 860*380*780mm | 1555*950*980mm | 850*460*765mm | 980*570*800mm | 980*570*800mm | 980*570*800mm | 980*570*800mm |
| Notes | During shipment, the tiller machine components are shipped separately from parts such as fenders and handlebars, without pre-assembly. Logistics shipping is typically done using wooden crates for container loading, with customizable carton packaging available upon request. | ||||||
In addition to the above parameters, we can also customize parameters and functions tailored to your needs.
cultivator machine farm cultivator can provide a relatively stable power output, and the rotational speed is relatively constant. This enables the tiller to maintain a uniform tilling force and speed during operation, and there will be no inconsistent tilling depth or stalling phenomena caused by power fluctuations, thus ensuring the stability of tilling quality.
Features
Durable Construction: High-grade steel and anti-corrosion coating ensure 10,000+ hours of operation.
Precision Farming: Optional GPS guidance for row accuracy (±2 cm).
Low Maintenance: Quick-release blades and grease-free bearings.
Eco-Friendly: Meets EU Stage V and EPA Tier 4 emission standards.
Versatility: Compatible with seeders, harrows, and plows.
Advanced Production Equipment
Our 20,000㎡ factory houses a fully automated assembly line, robotic welding systems, and a powder coating workshop. This ensures consistent quality, with 98% of components produced in-house for tighter quality control.
Rigorous Machine Testing
Every cultivator machine farm cultivator undergoes 72-hour endurance testing, including vibration simulations and load stress checks. Real-field trials in Africa and Southeast Asia validate performance under extreme conditions.
Why Choose US?
- 2-Year Warranty: Covers mechanical and electrical parts.
- Global Support: 26 overseas offices provide spare parts within 48 hours.
- Custom Solutions: Modify tilling width, power, or attachments to match your needs.
- Cost Efficiency: Bulk orders save up to 20% with flexible payment terms.
Certifications & Compliance
Our equipment meets CE, ISO8528, and GB/T 2820-97 standards, with ISO9001-certified management systems.
Global Exhibitions
We showcase innovations at Agritechnica, Farm Progress Show, and ASEAN AgriTech.
Packaging & Delivery
Machines are disassembled, crated in waterproof packaging, and shipped globally via air/sea freight. Delivery: 15–25 days.
After-Sales Service
24/7 technical support, on-site training, and a 10-year spare parts guarantee.
FAQ
Q: Do you offer financing options?
A: Yes! Leasing and installment plans are available.
Q: Can I request a demo?
A: We arrange free demos at your location.
Q: How do I order spare parts?
A: Contact your nearest overseas office or email Jean@whjlmech.com.
Boost Your Farm's Productivity Today!
Trusted by agri-cooperatives in 15+ countries, our cultivator machine farm cultivator delivers long-term value. Contact us at skala@whjlmech.com for quotes, catalogs, or custom requests.
