Diesel synchronous generator
Voltage: 220V–480V (customizable)
Speed(R.P.M):1500/1800
Frequency(HZ):50HZ/60HZ
Noise Level: 65–75 dB(A) at 7 meters
Dimensions: Compact to industrial-scale designs
Phase:Single/Three phaseType:Silent/Open Frame
Engine Type:Two/Four cylinder
Cooling System: Radiator-based or closed-loop
Starting Method:Electric starting
Customization: OEM/ODM
Certifications: CE, ISO8528, GB/T 2820-97
- Product Description
JLMECH：Your Trusted Diesel synchronous generator Partner
Our Diesel synchronous generator are built for one main job: to give you the most stable and reliable power possible. Think of them as the steady, dependable foundation for your most important equipment. They are the preferred choice when you need to start big motors or run multiple generators together smoothly.
Why Choose a Synchronous Generator?
Stable Power You Can Trust
Delivers constant voltage, so your sensitive machines and computers run safely without hiccups.
Handles sudden changes in power demand quickly and smoothly.
Starts Big Motors with Ease
Has the extra power "punch" needed to start large motors for pumps, compressors, and tools without straining.
Much more capable in this area than simpler, single-phase generators.
Works as a Team
Can be easily connected with other generators to create a larger, more reliable power system.
Perfect for growing your power capacity or having a backup ready (N+1 redundancy).
Ideal for:
Industrial Workshops & Factories with heavy machinery.
Construction Sites needing to run large equipment.
Farms with irrigation pumps and processing equipment.
Any business wanting to expand their power system reliably.
In short: If your work depends on steady power for tough jobs, a synchronous generator is the strong and smart choice.
Specifications
| Unit model | Power（KW） | Power（KVA） | current（A） | Engine model | Cylinder | Bore×Stroke | Displacement | Lube oil | fuel consumption ( g/kw.h) | Size（mm） | Weight（Kg） |
| JL-24GF | 24 | 30 | 43.2 | 4B3.9-G2 | 4 | 102*120 | 3.9 | 11 | 208 | 1620*710*1100 | 710 |
| JL-30GF | 30 | 37.5 | 54 | 4BT3.9-G2 | 4 | 102*120 | 3.9 | 11 | 208 | 700*710*1110 | 800 |
| JL-40GF | 40 | 50 | 72 | 4BTA3.9-G2 | 4 | 102*120 | 3.9 | 11 | 210 | 1800*800*1200 | 920 |
| JL-50GF | 50 | 62.5 | 90 | 4BTA3.9-G2 | 4 | 102*120 | 3.9 | 11 | 210 | 800*800*1200 | 950 |
| JL-64GF | 64 | 80 | 115.2 | 4BTA3.9-G11 | 4 | 102*120 | 3.9 | 11 | 210 | 1850*800*1200 | 1000 |
| JL-80GF | B0 | 100 | 144 | 6BT5.9-G2 | 6 | 102*120 | 5.9 | 16 | 210 | 2200*800*1200 | 1250 |
| JL-100GF | 100 | 125 | 180 | 6BTA5.9-G2 | 6 | 102*120 | 5.9 | 20 | 207 | 2200*800*1200 | 1300 |
| JL-120GF | 120 | 150 | 216 | 6BTAA5.9-G2 | 6 | 102*120 | 5.9 | 24 | 207 | 2250*800*1200 | 1350 |
| JL-132GF | 132 | 165 | 237.6 | 6BTAA5.9-G12 | 6 | 102*120 | 5.9 | 24 | 207 | 2300*820*1300 | 1350 |
| JL-150GF | 150 | 187.5 | 270 | 6CTA8.3-G2 | 6 | 114*135 | 8.3 | 24 | 207 | 2300*820*1330 | 1600 |
| JL-18DGF | 180 | 225 | 324 | 6CTAA8.3-G2 | 6 | 114*135 | 8.3 | 24 | 207 | 2550*1050*1480 | 1700 |
| JL-200GF | 200 | 250 | 360 | 6LTAA8.9-G2 | 6 | 114*145 | 8.9 | 28 | 207 | 2550*1050*1500 | 2000 |
| JL-220GF | 220 | 275 | 396 | 6LTAA8.9-G3 | 6 | 114*145 | 8.9 | 28 | 203 | 2550*1050*1500 | 2000 |
| JL-400GF | 400 | 500 | 720 | QSZ13-G2 | 6 | 130*163 | 13 | 28 | 201 | 3150*1360*1800 | 3200 |
| JL-450GF | 450 | 562.5 | 810 | QsZ13-G3 | 6 | 130*163 | 13 | 28 | 201 | 3160*1360*1800 | 3300 |
| JL-500GF | 500 | 625 | 900 | KTA19-G8 | 6 | 159*159 | 19 | 50 | 206 | 3500*1380*1800 | 4000 |
| JL-600GF | 600 | 750 | 1080 | KT38-GA | 12 | 159*159 | 38 | 100 | 206 | 4350*1800*2350 | 7000 |
| JL-700GF | 700 | 875 | 1260 | KTA38-G2B | 12 | 159*159 | 38 | 100 | 206 | 4350*1800*2350 | 7500 |
| JL-800GF | 800 | 1000 | 1440 | KTA38-G2A | 12 | 159*159 | 38 | 100 | 206 | 4350*1800*2350 | 7500 |
| JL-900GF | 9D0 | 1125 | 1620 | KTA38-G9 | 12 | 159*159 | 38 | 135 | 208 | 4450*1800*2350 | 8200 |
| JL-1000GF | 1000 | 1250 | 1800 | KTA38-G9 | 12 | 159*159 | 38 | 135 | 208 | 4450*1850*2350 | 8200 |
| JL-1100GF | 1100 | 1375 | 1980 | KTA50-G3 | 16 | 159*159 | 50 | 177 | 205 | 5000*2040*2430 | 9500 |
| JL-1200GF | 1200 | 1500 | 2160 | KTA50-G8 | 16 | 159*159 | 50 | 204 | 205 | 5350*2110*2500 | 10000 |
The rotational speed in the above Diesel synchronous generator technical parameters is 1500 RPM, the frequency is 50 Hz, the rated voltage is 400/230V, the power factor is 0.8, and the wiring method is three-phase four-wire. The 60 Hz generator sets and generator brands can be customized according to the special needs of customers. This parameter table is for reference only. For details, please contact our customer service.
Why Choose US?
- OEM Expertise: As an authorized partner for Cummins, we adhere to strict quality protocols.
- Custom Solutions: Tailor voltage, fuel efficiency, and control systems to your project.
- Global Support: 26 overseas offices in Africa and Southeast Asia ensure rapid technical assistance.
- Cost Efficiency: Optimized TCO (total cost of ownership) through energy-saving designs and extended service intervals.
Packaging and Delivery
Units are securely packaged in weatherproof crates with anti-corrosion treatments. Global shipping via sea/air freight available.
Company Profile
Wuhan Jlmech Co., Ltd. operates 11 branches across China and employs 126 technical experts, including 27 senior engineers. Our 35,000m² facility features automated assembly lines and rigorous testing systems, ensuring every Diesel synchronous generator meets international standards.
Factory After-Sales Service
Enjoy 24/7 technical support, a 2-year warranty, and guaranteed 48-hour spare parts delivery worldwide.
Certification
ISO9001, ISO14001, CE, and GS-certified manufacturing processes.
Exhibitions
We showcase innovations at PowerGen International, Middle East Energy, and regional trade shows.
FAQ
Q: Can I request a generator customized for high-altitude operations?
A: Yes! Our engineers adjust air-fuel ratios and cooling systems for performance at elevations up to 4,500 meters.
Q: What's the lead time for bulk orders?
A: 15–30 days, depending on specifications. Urgent orders prioritized.
Q: Do you offer financing options?
A: Flexible payment terms and leasing plans are available for large-scale procurement.
Q: Are your generators compatible with hybrid solar-diesel setups?
A: Absolutely. We design units to integrate with renewable energy systems.
Q: How do you ensure compliance with local emissions laws?
A: Each Diesel synchronous generator is pre-tested for regional regulatory alignment.
Power Your Projects with Confidence
Whether you're managing a mining operation in Africa or a data center in Southeast Asia, our Diesel synchronous generator guarantees reliability. Contact us at skala@whjlmech.com to discuss your requirements or request a free quote.
