30kVA diesel set
Rated AC Voltage(V)：220V/230V/380V/400V
Frequency(HZ):50
Engine Speed(R.P.M):1500
Phase:Single/Three Phase
Engine Type:4/6 cylinder
Cooling Method: Water Cooling
Starting Method:Electric Starting
Customization: OEM/ODM
Noise Level: ≤65 dB(A) at 1 meter
Fuel Efficiency: Optimized consumption for reduced operational costs
Certifications: CE, ISO8528, GB/T 2820-97, and EPA compliance
Optional Features: Automatic Transfer Switch (ATS), remote monitoring, and modular scalability
- Product Description
JLMECH：Your Trusted 30kVA diesel set Manufacturer & Supplier
As an established generator manufacturer with over two decades of industry experience, our factory specializes in developing dependable and efficient power solutions tailored to meet the evolving needs of global clients. Our 30kVA diesel set integrates robust engineering with intelligent features, making it an ideal choice for small to medium-sized enterprises seeking reliable and adaptable electricity supply.
30kVA Diesel Set Description
Broad Application Compatibility and User-Friendly Operation
Multi-Scenario Adaptability: This 30kVA diesel set is designed to serve a wide range of applications, including retail stores, farms, construction sites, and telecommunications facilities. Its flexible power output and compact structure ensure seamless integration into various environments without compromising performance.
Intuitive Control System: Equipped with a smart digital panel featuring clear indicators, multilingual support, and one-touch operation, the set allows users to monitor and manage power generation effortlessly, reducing the need for specialized technical knowledge.
Enhanced Mobility and Rapid Deployment: Available in skid-mounted or towable configurations, the unit can be quickly transported and installed, providing immediate power support for temporary or remote operations.
Quiet and Eco-Conscious Performance: Advanced noise reduction technology (below 70 dB at 7 meters) and compliance with international emission standards enable discreet and environmentally responsible operation.
Reliable Power Quality: With precise voltage regulation (±1%) and frequency stability (±0.5%), the set safeguards sensitive equipment and ensures consistent performance under varying load conditions.
Specifications
| Model | Power (KW) | Power (KVA) | Current( A) | Engine model | Cylinder | Bore×Stroke（mm） | Displacement (L) | Lube oil (L) | Consumption (g/kw.h) | Size (mm) | Weight (Kg) |
| JL-10GF | 10 | 2.5 | 18 | 403D-15G | 3 | 84*90 | 149 | 6 | 248 | 1250*700*1100 | 350 |
| JL-16GF | 16 | 20 | 28.8 | 404D-22G | 4 | 84*100 | 2.2 | 10.6 | 237 | 1500*710*1100 | 500 |
| JL-24GF | 24 | 30 | 43.2 | 1103A-33G | 3 | 105*127 | 3.3 | 79 | 211 | 1500*750*1100 | 800 |
| JL-50GF | 50 | 62.5 | 90 | 1103A-33TG2 | 3 | 105*127 | 3.3 | 79 | 215 | 1550*750*1180 | 1050 |
| JL-50GF | 50 | 62.5 | 90 | 1104A-44TG1 | 4 | 105*127 | 4.4 | 8 | 208 | 1800*750*1180 | 1100 |
| JL-80GF | 80 | 100 | 144 | 1104D-E44TAG2 | 4 | 105*127 | 4.4 | 8 | 216 | 1950*800*1200 | 1250 |
| JL-120GF | 120 | 150 | 216 | 1106A-70TAG2 | 6 | 105*135 | 7.01 | 16.5 | 208 | 2600*950*1450 | 1450 |
| JL-160GF | 160 | 200 | 288 | 1106A-70TAG4 | 6 | 105*135 | 7.01 | 16.5 | 220 | 2800*950*1450 | 2100 |
| JL-200GF | 200 | 250 | 360 | 1506A-E88TAG3 | 6 | 112*149 | 8.8 | 41 | 200 | 3100*1000*1700 | 2150 |
| JL-240GF | 240 | 300 | 432 | 1506A-E88TAG5 | 6 | 112*149 | 8.8 | 41 | 198 | 3100*1000*1700 | 2150 |
| JL-320GF | 320 | 400 | 576 | 2206C-E13TAG3 | 6 | 130*157 | 12.5 | 40 | 206 | 3350*1200*2000 | 3300 |
| JL-400GF | 400 | 500 | 720 | 2506C-E15TAG2 | 6 | 137*171 | 15.2 | 62 | 211 | 3450*1200*2100 | 3760 |
| JL-480GF | 480 | 600 | 864 | 2806C-E18TAG1A | 6 | 145*183 | 18.1 | 62 | 216 | 4100*1600*2200 | 4600 |
| JL-520GF | 520 | 650 | 936 | 2806A-E18TAG2 | 6 | 145*183 | 18.1 | 62 | 202 | 4200*1600*2200 | 4800 |
| JL-600GF | 600 | 750 | 1080 | 4006-23TAG2A | 6 | 160*190 | 22.9 | 113 | 202 | 4500*1800*2300 | 5500 |
| JL-720GF | 720 | 900 | 1296 | 4008TAG1A | 8 | 160*190 | 30.5 | 153 | 206 | 4800*2100*2500 | 7700 |
| JL-800GF | 800 | 1000 | 1440 | 4008TAG2A | 8 | 160*190 | 30.5 | 153 | 214 | 4900*2100*2500 | 8000 |
| JL-900GF | 900 | 1125 | 1620 | 4008TAG2 | 8 | 160*190 | 30.5 | 165 | 202 | 4900*2100*2500 | 8000 |
| JL-1000GF | 1000 | 1250 | 1800 | 4012-46TWG2A | 12 | 160*190 | 458 | 177 | 212 | 4950*2200*2550 | 8500 |
| JL-1100GF | 1100 | 1375 | 1980 | 4012-46TWG3A | 12 | 160*190 | 45.8 | 177 | 212 | 4950*2200*2550 | 8700 |
| JL-1200GF | 1200 | 1500 | 2160 | 4012-46TAG2A | 12 | 160*190 | 45.8 | 177 | 200 | 5050*2200*2550 | 9100 |
| JL-1360GF | 1360 | 1700 | 2448 | 4012-46TAG3A | 12 | 160*190 | 45.8 | 177 | 208 | 5050*2200*2550 | 9500 |
| JL-1600GF | 1600 | 2000 | 2880 | 4016-61TRG2 | 16 | 160*190 | 61.1 | 237 | 205 | 5800*2800*3100 | 14000 |
The rotational speed in the above Perkins generator set technical parameters is 1500 RPM, the frequency is 50 Hz, the rated voltage is 400/230 V, the power factor is 0.8, and the wiring method is three-phase four-wire. The 60 Hz generator sets and generator brands can be customized according to the special needs of customers. This parameter table is for reference only. For details, please contact our customer service.
Why Choose US?
- Proven Expertise: Over 52 engineers and 27 senior technicians refine every design.
- Global Compliance: Pre-configured for regional voltage, emissions, and noise regulations (e.g., SONCAP, SASO).
- OEM Partnerships: Trusted by Cummins, Perkins, and Liebherr for precision manufacturing.
- 2-Year Warranty: Comprehensive coverage for mechanical and electrical components.
- Fast Delivery: 26 overseas offices in Africa and Southeast Asia streamline logistics.
Packaging & Delivery
All units are securely crated with shock-resistant packaging and moisture-proof treatments. We offer flexible shipping options, including EXW, FOB, and CIF, with expedited delivery for urgent projects.
Company Profile
Wuhan Jlmech Co., Ltd. operates 11 branches across China and 26 international offices, supported by ISO9001 and ISO14001 management systems. Our state-of-the-art facilities include automated assembly lines and rigorous testing labs to guarantee product excellence.
Factory After-Sales Service
We provide 24/7 technical support, on-site maintenance, and genuine spare parts through our global network. Extended service contracts and operator training are available.
Certification
Our generators meet CE, ISO8528, and GB/T 2820-97 standards, with emissions aligned with EU Stage V and EPA Tier 4.
Exhibitions
We showcase innovations at global trade fairs like PowerGen Asia and Middle East Electricity.
FAQ
Q: What's the lead time for bulk orders?
A: Typically 15-30 days, depending on configuration and quantity.
Q: Do you offer noise-level testing reports?
A: Absolutely—third-party acoustic reports are provided upon request.
Ready to Secure Uninterrupted Power?
Contact Wuhan Jlmech at skala@whjlmech.com to discuss your 30kVA diesel set needs. Let's keep your operations running smoothly—and quietly.
