100kVA diesel set
Rated AC Voltage(V):400/380
Frequency(HZ):50
Engine Speed(R.P.M):1500
Phase:Three Phase
Type:Silent/Open Frame
Engine Type:3/4/6/8/12/16 cylinder
Cooling Method: Water Cooling
Starting Method:Electric Starting
Customization: OEM/ODM
Certificates: E/Euro 5/EPA/CARB
- Product Description
JLMECH:Your Trusted100kVA diesel set Manufacturer & Supplier
As an established diesel generator manufacturer, we provide robust power solutions tailored to your operational requirements. Our 100kVA diesel set represents an ideal balance of performance and durability, engineered to deliver consistent power where it matters most. We specialize in configuring this reliable power range to match your specific site conditions and operational demands.
Key Features of Our 100kVA Diesel Set
Our 100kVA diesel set is designed for continuous operation in demanding environments, delivering dependable performance through several critical features:
Consistent Power Output: Provides stable 100kVA (80kW) prime or standby power, capable of supporting small to medium industrial facilities, commercial complexes, agricultural operations, and construction sites
Enhanced Durability: Built with industrial-grade components including a heavy-duty engine block, large-capacity cooling system, and reinforced alternator for extended service life
Operational Efficiency: Features advanced fuel injection technology and optimized combustion design for reduced fuel consumption and lower operating costs
Environmental Adaptability: Engineered to maintain performance in diverse conditions with options for weatherproof enclosures, dust protection systems, and high-temperature operation capabilities
Specifications
| Unit model | Power（KW） | Power（KVA） | current（A） | Engine model | Cylinder | Bore×Stroke | Displacement | Lube oil | fuel consumption ( g/kw.h) | Size（mm） | Weight（Kg） |
| JL-15GF | 15 | 19 | 27.1 | 4B3.9-G1 | 4 | 102*120 | 3.9 | 11 | 198 | 1600*700*1100 | 900 |
| JL-15GF | 15 | 19 | 27.1 | 4B3.9-G2 | 4 | 102*120 | 3.9 | 11 | 198 | 1600*700*1100 | 900 |
| JL-20GF | 20 | 25 | 36.1 | 4B3.9-G2 | 4 | 102*120 | 3.9 | 11 | 198 | 1620*710*1100 | 900 |
| JL-24GF | 24 | 30 | 43.2 | 4B3.9-G2 | 4 | 102*120 | 3.9 | 11 | 208 | 1620*710*1100 | 710 |
| JL-30GF | 30 | 37.5 | 54 | 4BT3.9-G2 | 4 | 102*120 | 3.9 | 11 | 208 | 1700*710*1110 | 800 |
| JL-40GF | 40 | 50 | 72 | 4BTA3.9-G2 | 4 | 102*120 | 3.9 | 11 | 210 | 1800*800*1200 | 920 |
| JL-50GF | 50 | 62.5 | 90 | 4BTA3.9-G2 | 4 | 102*120 | 3.9 | 11 | 210 | 800*800*1200 | 950 |
| JL-64GF | 64 | 80 | 115.2 | 4BTA3.9-G11 | 4 | 102*120 | 3.9 | 11 | 210 | 1850*800*1200 | 1000 |
| JL-80GF | 80 | 100 | 144 | 6BT5.9-G2 | 6 | 102*120 | 5.9 | 16 | 210 | 2200*800*1200 | 1250 |
| JL-100GF | 100 | 125 | 180 | 6BTA5.9-G2 | 6 | 102*120 | 5.9 | 20 | 207 | 2200*800*1200 | 1300 |
| JL-120GF | 120 | 150 | 216 | 6BTAA5.9-G2 | 6 | 102*120 | 5.9 | 24 | 207 | 2250*800*1200 | 1350 |
| JL-132GF | 132 | 165 | 237.6 | 6BTAA5.9-G12 | 6 | 102*120 | 5.9 | 24 | 207 | 2300*820*1300 | 1350 |
| JL-150GF | 150 | 187.5 | 270 | 6CTA8.3-G2 | 6 | 114*135 | 8.3 | 24 | 207 | 2300*820*1330 | 1600 |
| JL-180GF | 180 | 225 | 324 | 6CTAA8.3-G2 | 6 | 114*135 | 8.3 | 24 | 207 | 2550*1050*1480 | 1700 |
| JL-200GF | 200 | 250 | 360 | 6LTAA8.9-G2 | 6 | 114*145 | 8.9 | 28 | 207 | 2550*1050*1500 | 2000 |
| JL-220GF | 220 | 275 | 396 | 6LTAA8.9-G3 | 6 | 114*145 | 8.9 | 28 | 203 | 2550*1050*1500 | 2000 |
| JL-400GF | 400 | 500 | 720 | QSZ13-G2 | 6 | 130*163 | 13 | 28 | 201 | 3150*1360*1800 | 3200 |
| JL-450GF | 450 | 562.5 | 810 | QsZ13-G3 | 6 | 130*163 | 13 | 28 | 201 | 3160*1360*1800 | 3300 |
The rotational speed in the above Cummins generator set technical parameters is 1500 RPM, the frequency is 50 Hz, the rated voltage is 400/230 V, the power factor is 0.8, and the wiring method is three-phase four-wire. The 60 Hz generator sets and generator brands can be customized according to the special needs of customers. This parameter table is for reference only. For details, please contact our customer service.
Why Choose US?
- Proven Expertise: 26 overseas offices and 11 branches ensure localized support.
- OEM Experience: Trusted by Cummins, Doosan, and Liebherr for precision engineering.
- Advanced Facilities: Automated assembly lines and rigorous testing guarantee quality.
- Global Compliance: CE, ISO8528, and emission certifications simplify cross-border procurement.
Packaging and Delivery
All 100kVA diesel set units are securely packed in weatherproof crates with anti-corrosion treatments. Delivery timelines: 15–25 days (standard orders) or customized per bulk requirements.
Company Profile
With 3 R&D hubs and 52 engineers, Wuhan Jlmech combines innovation with practicality. Our 26 overseas offices in Africa and Southeast Asia ensure seamless logistics and after-sales service.
Factory After-Sales Service
Enjoy a 2-year warranty, 24/7 technical support, and readily available spare parts.
Certification
ISO9001, ISO14001, CE, and GB/T 2820-97 certified.
Exhibitions
Regular exhibitors at global trade shows like Bauma and PowerGen.
FAQ
Q: What's the lead time for 10+ units?
A: Bulk orders ship within 20 days with priority scheduling.
Q: Do you provide onsite installation support?
A: Our technicians offer global commissioning services.
Q: How does your pricing compare to solar hybrids?
A: We provide competitive upfront costs with lower lifetime maintenance expenses.
Power Your Projects with Confidence
Whether you're powering a mining site or securing backup for a data center, our 100kVA diesel set combines rugged reliability with cost-efficiency. Backed by Wuhan Jlmech's 29-year legacy, we're ready to support your energy needs.Contact Us Today: Email skala@whjlmech.com for quotes or technical queries. Let's keep your operations running smoothly!
